Ugo Basile

Librae - Incapacitance Tester for mice & rats
Code: 47883/47882

Librae - Incapacitance Tester for mice & rats Featured

Your 21st century Incapacitance Tester

The Ugo Basile Incapacitance Tester is here!

Unique features:

  • Bright touch screen
  • USB data storage and direct Excel export
  • Magnetic pads for easy cleaning
  • Restrainers for mice (SKU 47883) and rats (SKU 47882).
  • Pedal switch and restrainer Included

Measure hind paw weight distribution, through the most widely used method (>1,500 citations), now updated and equipped with the latest technologies by Ugo Basile.

Autostart is a unique feature.

Automate the measurement process by identifying immobility windows. The autostart feature developed by UGO Basile turns the procedure into a fully operator independant process.

Touch screen and USB data storage let scientists setting, controlling and managing instrument data quickly and seamlessly.

Through a few, intuitive buttons, one can reach all the functionalities. The included USB key stores all data for optimal portability (average paw weight, Standard Deviation, Left/Right ratio, etc.). The Left/Right weight histograms and scatter charts display on line the experiment output for an immediate visual control, graphically effective and easy to follow during the test.

Reliable and easy to collect results: high quality force sensors (0.1g resolution) are easily calibrated with the provided reference weight and show no screws or other parts potentially interfering with the animal, for maximum experiment repeatability. After each test the result can be stored or discarded and data can be transferred from the instrument to a PC for MS Excel.
At the end of the experiment the foot pads can be cleaned in a few seconds, being magnetically attached to the base.


Additional Info

    FEATURES

    BENEFIT

    Measure hind paw weight distribution

    Through the most widely used method (>1,500 citations), now updated and equipped with the latest technologies by Ugo Basile.

    Autostart is a unique feature

    Automate the measurement process by identifying immobility windows. The autostart feature developped by UGO Basile turns the procedure into a fully operator independant process.

    Touch screen and USB data storage

    Let scientists setting,
    controlling and managing instrument data quickly and seamlessly. Through a few, intuitive buttons, one can reach all the functionalities. The included USB key stores all data for optimal portability (average paw weight, Standard Deviation, Left/Right ratio, etc.). The Left/Right weight histograms and scatter charts display on line the experiment output for an immediate visual control, graphically effective and easy to follow during the test.

    Reliable and easy to collect results:, software included

    High quality force sensors (0.1g resolution) are easily calibrated with the provided reference weight and show no screws or other parts potentially interfering with the animal, for maximum experiment repeatability. After each test the result can be stored or discarded and data can be transferred from the instrument to a PC for MS Excel.
    At the end of the experiment the foot pads can be cleaned in a few seconds, being magnetically attached to the base.




    General



    Measurements resolution:

    0.05 g @ 500 g scale; 0.1 g @ max scale (2.200 g per paw)

    Max. weight and accuracy:

    2.200 g per paw and 0.5% full scale

    Measurement time:

    From 1 s to 360 s

    Measurement starting mode:

    Manual or Automatic with automode settings.

    Output data file:

    .csv format (to be open also in Microsoft Excel)

    Designed for:

    Mice and Rats.

    Physical



    Dimensions:

     13 cm x 25 cm x 31 cm (HxWxD) without holders.

    Packaging dimension:

    28 cm x 68 cm x 34 cm (HxWxD) Weight 3.0 Kg.

    Weight:

    2.6 Kg (instrument only no pedal, holders and power cable)

    Dimensions

    87x64x64(h)cm

    Weight

    39Kg

    Shipping Weight

    41Kg (Carton box)

    Power supply:

    Internal power supply 90-260VAC, fanless (silent)

    Warranty

    Librae is covered by a 12 + 12 month warranty by product registration

    47883

    Just for mice -Librae Incapacitance tester for mouse, max load 2.2Kg. resolution 0.1 g, USB data export, self calibration and autostart modes, mouse restrainer, pedal switch, calibration weight,  Included

     47882

    Just for rat -Librae Incapacitance tester for rat, max load 2.2Kg.resolution 0.1 g, USB data export, self calibration and autostart modes, rat restrainer, pedal switch, calibration weight,  Included

    47885

    For mice & rat -Librae Incapacitance tester for mouse and rat, max load 2.2Kg. resolution 0.1 g, USB data export, self calibration and autostart modes, mouse and rat restrainer, pedal switch, calibration weight,  Included

    47880-001 Librae Incapacitance tester, max load 2.2Kg. per paw, resolution 0.1 g, USB data export, self calibration and autostart modes, no restrainer, pedal switch, calibration weight, Included
    47880-002 Librae Incapacitance tester restrainer for rat in clear perspex, width 64 mm
    47880-003 Librae Incapacitance tester restrainer for mice in clear perspex, width 40 mm
    47880-320 Librae Incapacitance tester calibration weight 100 gr.
    47880-321 Librae Incapacitance tester magnetic pads (pair left + right)
